KIND DD+ 4000 Усилитель мощности
750/8 - 1250/4 - 2000/2,
класс D, 2U,
10 кg
149735,92 ₽ |
|
Оплата
|
Доставка
|
Описание
2-канальный усилитель мощности. Серия DD+ разработана для самых требовательных пользователей,основана на схематехнике усилителей класса D с запатентованным модулятором. Преимуществами этой технологии являются низкое выделение тепла, компактный размер и бескомпромиссный звук. Отраженная энергия от громкоговорителя как активной нагрузки перерабатывается блоком питания. Потребление энергии из сети переменного тока снижается, в то время как больше энергии отдается громкоговорителю.
Усилитель мощности профессиональный туринговый KIND DD+ 4000
- Number of channels : 2
Power Output Per Channel (EIA 1kHz - 1% THD @ 230 V AC) (all channels driven)
- 16 ohms per ch. : 430 W
- 8 ohms per ch. : 750 W
- 4 ohms per ch. : 1250 W
- 2 ohms per ch. : 2000 W
- 70V Direct Drive2 : 1250W (Internal 75Hz HPF enabled for this use)
Power Output Bridged Per Channels Pair (EIA 1kHz - 1% THD @ 230 V AC)
- 16 ohms : 1500 W
- 8 ohms : 2500 W
- 4 ohms : 4000 W
- 70V Direct Drive2) : 4000W (Internal 75Hz HPF enabled for this use)
- 100V Direct Drive2) : 2500W (Internal 75Hz HPF enabled for this use)
- Performance With Gain : 32 dB
- THD+N 20 Hz - 20kHz for 1 W @ 4 ohms : <0.2%
- THD @ 1 kHz 1dB below clipping @ 4 ohms: <0.35%
- Signal to Noise Ratio : >102 dBA
- Frequency Response (1 W @ 8 ohms) +0/-1dB 20Hz - 20kHz
- Damping Factor @ 8 ohms load, 10 Hz to 200 Hz : >200
- Output Slew rate @ 8 ohms (input filter bypassed) : 45V /uS
- Input Impedance Balanced / Unbalanced : 20k / 10kOhm
- Input CMRR : >50 dB
Gain and Level
- Input Sensitivity @ 4 ohms (32 dB gain) +/- 3 % : 1.78 V
- Input Gain Selectable (DIP switches on rear panel) : 26, 29, 32, 35, 38, 41, 44dB
- Default Gain : 32 dB
- Level Adjustment (per channel) : Front panel potentiometer, 21 pos. stepped gain from -Inf to 0 dB
Front panel Indicators
- Common : Active on (normal status), Active off (mute); Hi temperature (blinking for power reduction and on for mute); Digital Signal Processor (DSP) present
- Per channel : Signal output -35 dB, -20 dB, -10 dB; Clip / Limit; Protect
Connectors and switches
- Input connectors (per channel) : Balanced: Neutrik Combo™ (XLR female and 1/4” jack), XLR pin 2 and TRS tip positive, and XLR male for link, pin 2 positive
- Output connectors (per channel) : Neutrik Speakon™ (bi-wiring connected)
- Output bridge mode per two channels : A+B - ch. A is signal input source; C+D - ch. C is signal input source.
- Rear panel 2 position DIP switches : Ch.’s A+B (C+D) link/Bridge on
- Rear panel 6 position DIP switches : Ch. A / B (C / D) High Pass Filter 30 / 75 Hz on; Gain multiple selection
- Power (on/off) : switch on front panel
- Output Circuitry : Class D
- Power Supply : (R-SMPS) Regulated Switch Mode Power Supply with PFC (Power Factor Correction); The unit works anywhere in the world
- Cooling : Two / three fans, front to rear air flow, temperature controlled speed; front panel removable dust filter
- Amplifier and Load Protection : Short circuit, open circuit, thermal, RF protection, mains over / lower voltage. On/off muting, DC fault shutdown, clip limiter
Power / Thermal
- Operating voltage : 95 - 265V AC - 50/60 Hz, min. power up voltage 80 V;
- Current draw @ 230 V AC 1/8 power 4 ohms : 2.1 A
- Current draw @ 230 V AC 1/4 power 4 ohms : 3.8 A
- Current draw @ 230 V AC, idle : 0.4 A
- Soft start / Inrush current draw @230 V AC : Yes / max. 2 A
- AC cordset : 230 V CE: 16 A, CEE7; 115 V ETL: 18A/NEMA L5-30P
- Thermal emission (BTU/Huor) @ 1/8 power 4 ohms : 517
- Thermal emission (BTU/Huor) @ 1/4 power 4 ohms : 784
- Options : Digital Signal Processing board (KIND DSP board-1), handles
- Dimensions : (W/H/D) W: 483 mm (19”), H: 88.9 mm (3.5” - 2 RU), Overal with optional handles D: 490 mm (19.29”), From front mounting rails D: 455 mm (17.91”)
- Weight - Net / Shipping 10 kg (22 lbs.) / 13 kg (28.6 lbs)
- Approvals CE EN55103-1 (Emissions), EN55103-2 (Immunity), EN60065, Class I (Safety)
483. Паспорт KIND DD+4000 (ing)
